Product Details:
Payment & Shipping Terms:
|
| Type: | Inkjet Printer | Color & Page: | Multicolor |
|---|---|---|---|
| Usage: | Card Printer, Label Printer, Paper Printer, Tube Printer, Cloths Printer, Phone Case,pen,USB,glass,ceramic | Plate Type: | Flatbed Printer |
| Condition: | New | Dimensions(L*W*H): | 3900*4000*1500mm |
| Weight: | 1980KG | Automatic Grade: | Semi-Automatic |
| Voltage: | 110V/220V | Warranty: | 3 Years |
| Print Dimension: | 2m*3m | Ink Type: | UV Led Ink |
| High Light: | uv flatbed printing machine,digital flatbed led uv printer |
||
UV Flatbed Digital Printing Machine For Advertising Printing Industry
| SPECIFICATIONS FOR UV2513 flatbed printer | |||
|
Print Resolution |
Speed model | 360*1440dpi | >=50m2/per hour |
| Standard model | 720*1440dpi | >=25m2/per hour | |
| High quality model | 1440*1440dpi | >=12m2/per hour | |
|
Main performance parameters |
Gen 5 Print head of Japan Ricoh | ||
| UV Curing System with LED UV lamp (Water Cooling) | |||
| Smart Bi-directional Printing Mode Drop-on-demand Piezo Electric Inkjet | |||
| Features |
* Auto heightmeasurement * Positive pressure Auto cleaning system * Dual negative pressure ink supply system * Aluminum double filter ink box * 3 in 1 high speed CPU servo driver |
||
| CMYK / CMYK+LC+LM+WW / CMYK+W+V / CMYK+LC+LM+W+V | |||
| Height Adjustment | Automatic with height Sensor. | ||
| Printing Method | Drop-on-demand Piezo Electric Inkjet | ||
| UV Curing System | LED UV Light (Water Cooling system) | ||
| Printing Method | Drop-on-demand Piezo Electric Inkjet | ||
| Printing Direction | Smart Bi-directional unidirectional Printing Mode | ||
Quick Details:
Product name: UV Flatbed printing machine
Printhead: Ricohh G5 Printhead
Print size: 2000*3000mm
Application: Glass,wall paper,Phone case.Card.Hairpin .personalized Printing
UV Curing System: LED UV lamp (Water Cooling)
Printing type: UV inkjet printing
Service Life: 3-4 years
Colors Printing: CMYK+4W/CMYK+LCLM+W
Printhead No.: 2/3/4/5/6/8/16
After-sales Service Provided: Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Engineers available to service machinery overseas
Applicable Industries: Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Printing Shops, Construction works , Advertising Company
Advantages:
1. Our machine can print material includes rigid sheets, such as glass, metal, acrylic, PVC board, MDF, and the flexible material, like film, leather, canvas, wall paper, ceiling paper etc.
2. We can provide the printer with excellent performance & competitive price.
3. You will enjoy our one-stop service.
Product Application
UV Printer is a high-tech film-free full color digital printing machine: It is suitable to print on any materials,Such as sliding doors, cabinet doors, wooden doors, glass, plates, signs, crystal, PVC, acrylic , Metal, plastic, stone, leather and other surface color photo-level printing. No need to plate once the printing is completed, rich and colorful colors, abrasion resistance, UV protection, easy operation, printing images fast, in full compliance with industrial printing standards.
